Gasket For Bs 4825 Clamp Fittings
Data Sheet: C3-109

Gasket For Bs 4825 Clamp Fittings




Description

Application examplesIn specific design envelope PTFE gaskets with EPDM insert for BS 4825 fittings

ApplicationsAcids, Strong alkali, Solvents, Catalyzers, Aromatics, Foods, Pharmaceuticals, Chemicals, Petrochemicals, etc.
The PTFE envelope is a protective barrier to the internal acid resistant rubber, wich for a limited period retains its elasticity.
• Operating temperature: -40° C +120° C
• Operation lifetime: medium


Gaskets dimensions
DN ØA ØB C
25 - 1" 50,5 22,1 1,7
32 - 1 ¼" 50,5 35,1 1,7
40 - 1 ½" 64 47,4 1,7
50 - 2" 77,5 60,5 1,7
65 - 2 ½" 91 73,2 1,7
80 - 3" 119 97,5 1,7
100 - 4" 167 146,9 1,7
