Y Filter in PTFE ANSI

Data Sheet: A3-72

Y Filter in PTFE

Standard Supply

Features

Design:

ANSI B16,5 Cl. 150
Flange: Fixed

Range:

DN 25 - DN 200
Until DN 150 PN 16
Until DN 250 PN 10

Metallic parts:
body: P245 GH EN 10216-2
flange: P235 GH EN 1092-1

Interior lining:

PFA

Filter cartridge coating:

PTFE

standard finishing

Available on request

DN	L [mm]	H [mm]	D [mm]	k [mm]	d1 [mm]	n x ØF [num x mm]
1"	160	125	107,9	79,4	51	4 x 15,9
1 1/2"	200	145	127	98,4	73	4 x 15,9
2"	230	165	152,4	120,6	92	4 x 19
3"	310	210	190,5	152,4	127	8 x 19
4"	350	310	228,6	190,5	157	8 x 19
6"	480	370	279,4	241,3	216	8 x 22,2
8"	600	580	342,9	298,4	270	8 x 22,2

Technical specifications of Difline products
